Easy... • Connects to your personal computer • Comes with it's own easy-to-use software. • Create, edit and save a variety of labels Versatile... • Print graphics, logos, bar codes, data records and more • Wide variety of tape supply available. Saves Time... • Compatible with most Windows software • Print labels from data already keyed into programs like Microsoft® Word and Excel. Has it's Own Software... The K3100 now comes with Kroy Label Designer Software (KLDS) and Windows print drivers.

Whether you need general-purpose or industrial-strength labeling, bar coding, or tamper-evident identification - even heat-shrink tubing - The K3100-PC provides the widest variety of specialized media available. All supplies are housed in a self-contained cartridge for rapid supply change.
	Printing Specifications • Thin film print head • 300 dots per inch (12 dots per mm) • Maximum print width .97" (24.7mm) • Maximum label width 1" (25.4mm) • Maximum print length 7.98" (202.7 mm) Print Speed • Vary by supply type Media • Total thickness 4.1 mil, 6 mil maximum • Cut off mode - continuous Physical • Printer module LxWxH - 6" x 4" x 4.375" • Total weight 1.8 lbs (.8 kg) Electrical • AC adapter version: Input 100 - 250VAC, 50/60 Hz, 43W output 9VDC, 4.7A - UL listed, CSA certified, TUV "GS" approval, CE recognized • Meets VDE-B and FCC part 15 class B RFI limits Communications • RS 232 (Db 9 male) • 9600 baud, No parity, 8 bits, hardware protocols Environmental • Operating temperature 45° to 105° F (7° to 40° C) • Machine storage temperature range -20° to 150° F (-30° to 65° C) • Supply cartridge storage temperature range 60° to 105° F (15° to 40° C) • Operating and storage humidity limit - 90% RH non-condensing Requirements • PC or compatible computer with,, Windows 95/98/2000 and Windows NT • One free com port • Hard disk with enough space to install driver files (Normally less than 1 MB) Part Number • K3100-PC with AC adapter, serial cable, KLDS software, and print driver cassette (2554400)		General Purpose: Adhesive-backed laminated and non-laminated thermal-transfer supply in assorted colors for general office use.
			Direct Thermal: Economical paper supply with the option of refillable cartridges.
			Industrial: Ideal for exterior use and harsh environments. Resists abrasion, UV light, chemicals, water and temperature extremes.
			Die Cut: Available in a variety of sizes in polyester and Kimdura®
			Tamper Evident: For security and safety. Provides a "VOID" message if the labels is tampered with.
			Polyolefin Shrink Tubing: Mark wires, cables and small piping. Self-Laminating Wire Markers Now you can label wires, cables and small piping that has already been installed!
